26
Straight Shank (SD)
TB TL
(REQ)
BD BL L
Order #
.625”
.315
1.25 1.06 1.72 2.40
0600-1
.750”
.315
1.25 1.06 1.72 2.40
0600-2
1.00”
.315
1.25 1.06 1.72 2.40
0600-3
12mm
.315
1.25 1.06 1.72 2.40
0600-12
16mm
.315
1.25 1.06 1.72 2.40
0600-16
20mm
.315
1.25 1.06 1.72 2.40
0600-20
22mm
.315
1.25 1.06 1.72 2.40
0600-22
25mm
.315
1.25 1.06 1.72 2.40
0600-25
Slater Tools is the leading manufacturer of high
quality, compact Rotary Broaching Tool Holders
designed specifically for Swiss type and other
precision machines.
The Adjustment-Free Rotary Broach Tool
Holder reduces set-up time and helps eliminate
operator error in any CNC mill or lathe. Simply
set the Adjustment-Free Tool Holder into your
machine and you are ready to rotary broach.
INTERNAL ADJUSTMENT-FREE ROTARY BROACH TOOL HOLDERS
•
EMAIL:
ADJUSTMENT-FREE ROTARY BROACH TOOL HOLDERS
INTERNAL
SMALL SWISS TYPE TOOL HOLDER
SMALL SWISS TYPE LONG TOOL HOLDER
.
315” TOOL BORE
|
BROACHING CAPACITY .028-.375”
|
2.00” LONG STRAIGHT SHANK
.
315” TOOL BORE
|
BROACHING CAPACITY .028-.375”
|
4.00” LONG STRAIGHT SHANK
Straight Shank (SD)
TB TL
(REQ)
BD BL L
Order #
.750”
.315
1.25 1.06 1.72 2.40
0600-2L
1.00”
.315
1.25 1.06 1.72 2.40
0600-3L
20mm
.315
1.25 1.06 1.72 2.40
0600-20L
22mm
.315
1.25 1.06 1.72 2.40
0600-22L
25mm
.315
1.25 1.06 1.72 2.40
0600-25L
INTERNAL ADJUSTMENT-FREE TOOL HOLDER BENEFITS:
• No center-indicating required
• Industry-best tool clearance eliminates tool interference
• High-durability three piece bearing configuration
• Conveniently offered in different shank sizes
• Eliminates secondary operations
• Capable of producing small external forms
