OVERALL LENGTH
X
Y
Z
Order #
.50
.75
.44
.09
1001-2
.62
.75
.44
.09
1001-4
.75
.75
.44
.09
1001-6
1.00
.75
.44
.09
1001-8
OVERALL LENGTH
X
Y
Z
Order #
.75
1.40
.75
.12
1002-2
1.00
1.40
.75
.12
1002-4
1.25
1.40
.75
.12
1002-6
1.50
1.40
.75
.12
1002-8
OVERALL LENGTH
X
Y
Z
Order #
1.00
2.06
1.38
.50
1003-2
1.25
2.06
1.38
.50
1003-4
1.50
2.06
1.38
.50
1003-6
1.75
2.06
1.38
.50
1003-8
.9448” MOUNTING DIAMETER
1.5748” MOUNTING DIAMETER
2.3125” MOUNTING DIAMETER
EXTERNAL BROACH BLANKS
Available from stock and wire-ready, these External
Rotary Broach Blanks are made from high-quality M2
high-speed tool steel. Slater Tools also offers Rotary
Broach Blanks made from PM4.
BROACH BLANKS
EXTERNAL
23
PHONE:
(586) 465-5000
•
FAX:
(586) 465-3030
NOTE: All dimensions in inches unless otherwise specified
