Standard Size
(in)
# OF TEETH
B
Order #
11/32”
12
.3480
503-3480
16
.3480
505-3480
21
.3480
507-3480
3/8”
14
.3790
503-3790
18
.3790
505-3790
23
.3790
507-3790
13/32”
15
.4100
503-4100
19
.4100
505-4100
24
.4100
507-4100
7/16”
16
.4415
503-4415
21
.4415
505-4415
26
.4415
507-4415
15/32”
17
.4730
503-4730
22
.4730
505-4730
28
.4730
507-4730
1/2”
18
.5040
503-5040
24
.5040
505-5040
30
.5040
507-5040
9/16”
20
.5665
503-5665
27
.5665
505-5665
34
.5665
507-5665
5/8”
23
.6290
503-6290
30
.6290
505-6290
38
.6290
507-6290
21/32”
24
.6600
503-6600
31
.6600
505-6600
39
.6600
507-6600
11/16”
25
.6915
503-6915
33
.6915
505-6915
41
.6915
507-6915
3/4”
27
.7540
503-7540
36
.7540
505-7540
45
.7540
507-7540
.500” SHANK DIAMETER
|
1.75” OVERALL LENGTH
12
INTERNAL SERRATION BROACHES
Slater Tools offers precision ground Internal Serration Rotary
Broaches designed to be used individually or as mating parts with
Slater’s External Standard Serration Rotary Broaches (see page 20).
When mating the internal with the external serration, there will be
a .0028” per side tooth clearance. Internal and External Serration
Rotary Broaches can be produced with a variety of custom options.
For all available broach options, see page 13.
Standard Size
(in)
# OF TEETH
B
Order #
5/16”
11
.3165
303-3165
15
.3165
305-3165
19
.3165
307-3165
11/32”
12
.3480
303-3480
16
.3480
305-3480
21
.3480
307-3480
3/8”
14
.3790
303-3790
18
.3790
305-3790
23
.3790
307-3790
.315” SHANK DIAMETER
|
1.25” OVERALL LENGTH
•
