.315” SHANK DIAMETER
|
1.25” OVERALL LENGTH
|
FORM SIZE RANGE .028-.650”
.500” SHANK DIAMETER
|
1.75” OVERALL LENGTH
|
FORM SIZE RANGE .080-1.300”
6
Standard Size
(in)
B
D
Order #
1/16” .064
.81
306-064
5/64” .079
.81
306-079
3/32” .095
.81
306-095
7/64” .1 1 1
.75
306-1 1 1
1/8”
.127
.75
306-127
9/64” .142
.75
306-142
5/32” .159
.75
306-159
11/64” .174
.75
306-174
3/16” .190
.75
306-190
7/32” .222
.62
306-222
1/4”
.253
.62
306-253
9/32” .284
.62
306-284
5/16” .316
.62
306-316
11/32” .347
.62
306-347
3/8”
.379
.62
306-379
13/32” .410
.62
306-410
Standard Size
(in)
B
D
Order #
3/32” .095
1.00 506-095
7/64” .1 1 1
1.00 506-1 1 1
1/8”
.127
1.00 506-127
9/64” .142
1.00 506-142
5/32” .159
1.00 506-159
3/16” .190
1.00 506-190
7/32” .222
.88 506-222
1/4”
.253
.88 506-253
9/32” .284
.88 506-284
5/16” .316
.88 506-316
11/32” .347
.75
506-347
3/8”
.379
.75
506-379
13/32” .410
.75
506-410
7/16” .442
.75
506-442
15/32” .473
.75
506-473
1/2”
.505
.75
506-505
17/32” .536
.75
506-536
9/16” .568
.75
506-568
19/32” .599
.75
506-599
5/8”
.631
.75
506-631
21/32” .662
.75
506-662
11/16” .694
.75
506-694
23/32” .725
.75
506-725
3/4”
.757
.75
506-757
Metric Size
(mm)
B
D
Order #
1.25mm
.051 .81
306-051
1.50mm
.061 .81
306-061
2.00mm
.081 .81
306-081
2.50mm
.101 .81
306-1 0 1
3.00mm
.121 .75
306-1 2 1
4.00mm
.161 .75
306-1 6 1
5.00mm
.200 .62
306-200
6.00mm
.240 .62
306-240
7.00mm
.279 .62
306-279
8.00mm
.320 .62
306-320
9.00mm
.358 .62
306-358
10.00mm .399 .62
306-399
11.00mm
.437 .62
306-437
12.00mm .478 .62
306-478
Metric Size
(mm)
B
D
Order #
2.00mm
.081 1.00 506-081
2.50mm
.101 1.00 506-1 0 1
3.00mm
.121 1.00 506-1 2 1
4.00mm
.161 1.00 506-1 6 1
5.00mm
.200 .88
506-200
6.00mm
.240 .88
506-240
7.00mm
.279 .88
506-279
8.00mm
.320 .88
506-320
9.00mm
.358 .75
506-358
10.00mm .399 .75
506-399
11.00mm
.437 .75
506-437
12.00mm .478 .75
506-478
13.00mm .517 .75
506-517
14.00mm .557 .75
506-557
15.00mm .597 .75
506-597
16.00mm .636 .75
506-636
17.00mm .678 .75
506-678
18.00mm .715 .75
506-715
19.00mm .758 .75
506-758
INTERNAL HEXAGON BROACHES
Slater Tools offers a large inventory of Hexagon Rotary Broaches.
The below listed sizes are available for immediate delivery in a
variety of materials and coatings. Additional popular sizes are also
available from stock. Slater Tools can make any custom size hex in
only 1-2 days. Across-the-flats dimensions conform to IFI and ANSI/
ASME standards for maximum tool life. We also offer pressure relief
vent holes, quantity discounts and re-sharpening services.
•
