CUSTOM INTERNAL AND EXTERNAL ROTARY BROACHES
MADE BASED ON YOUR PRINT AND TO YOUR SPECIFICATIONS
Because Slater Tools designs and manufactures everything
in-house, we are able to offer extremely quick turn-around
time for all special forms. Any internal or external shape
can be produced to suit your specific application. Custom
broaches can also be made to ANSI and SAE specifications.
Our most popular special form broaches include double D,
involutes, keyways, serrations, six lobe (hexalobular), Rosan-
type and splines. Custom broaches can be produced with a
variety of available broach options.
24
•
EMAIL:
AVAILABLE BROACH OPTIONS:
• Coatings: TiN, TiCN, TiAlN
• Materials: M2, PM4, T15 High Speed Tool Steels
• Different overall lengths
• Custom cut lengths (internal broaches)
• Custom dimensions
• MICRO forms
• Corner radius
• Spun ground diameter on broach corners (internal broaches)
• Single or double vent holes (internal broaches)
• Form can be aligned with flat on shank or slot (for holding orientation)
• Re-sharpening
• Quantity discounts at 5, 10, 30, 50, 100, 150, 200 pieces
CUSTOM BROACH ORDER PROCESS
• Please submit a portion of your print showing the area to be broached.
• You will receive a quote along with technical recommendations to ensure successful broaching.
• Once the order is placed, we will design your tool and submit a drawing for your approval.
• Manufacturing begins upon approval and takes only 5-10 business days.
CUSTOM ROTARY BROACHES
INTERNAL AND EXTERNAL
